NAD C 565BEE - Page 49

- 49 -
R10, R37, R38 4723-104A+P-R RMG 1/16W 100K 1% 0603
R15 4723-223A+P-R RMG 1/16W 22K 1% 0603
R73 4723-471A+P-R RMG 1/16W 470R 1% 0603
R100, R101, R102, R103, R46, R5, R96, R97, R98, R99 4723-473A+P-R RMG 1/16W 47K 1% 0603
R18 4723-560J+P-R RMG 1/16W 56R 5% 0603
JP1, JP15 4723-000J+P-R RMG 1/16W 0R 5% 0603
JP2 4723-332A+P-R RMG 1/16W 3.3K 1% 0603
JP3, JP4 4723-000J+P-R RMG 1/16W 0R 5% 0603
JP5 4723-472A+P RMG 1/16W 4.7K 1%.
JP6 4723-133A+P-R RMG 1/16W 13K 1% 0603
R11 4723-472A+P RMG 1/16W 4.7K 1%.
R2 4723-154A+P-R RMG 1/16W 150K 1% 0603
R21 4723-101A+P RMG 1/16W 100R 1% 0603
R24 4723-000J+P-R RMG 1/16W 0R 5% 0603
R25, R26 4723-270A+P RMG 1/16W 27R 1% 0603
R29 4723-221A+P RMG 1/16W 220R 1%
R3 4723-153A+P RMG 1/16W 15K 1%
R30, R31, R32 4723-105A+P RMG 1/16W 1M 1% 0603
R33, R34 4723-153A+P RMG 1/16W 15K 1%
R35 4723-331A+P RMG 1/16W 330R 1% 0603
R4 4723-334J+P RMG 1/16W 330K 5%
R40 4723-101A+P RMG 1/16W 100R 1% 0603
R43, R44 4723-000J+P-R RMG 1/16W 0R 5% 0603
R54 4723-000J+P-R RMG 1/16W 0R 5% 0603
R55, R56 4723-101A+P RMG 1/16W 100R 1% 0603
R6 4723-472A+P RMG 1/16W 4.7K 1%.
R60 4723-220A+P RMG 1/16W 22R 1% 0603
R62 4723-220A+P RMG 1/16W 22R 1% 0603
R63 4723-472A+P RMG 1/16W 4.7K 1%.
R64 4723-220A+P RMG 1/16W 22R 1% 0603
R65 4723-391A+P RMG 1/16W 390R 1%
R68 4723-152A+P-R RMG 1/16W 1.5K 1% 0603
R7 4723-910A+P RMG 1/16W 91R 1% 0603
R70 4723-102A+P RMG 1/16W 1K 1%
R71 4723-103A+P-R RMG 1/16W 10K 1% 0603
R72 4723-153A+P RMG 1/16W 15K 1%
R75, R76, R77 4723-220A+P RMG 1/16W 22R 1% 0603
R9 4723-562A+P RMG 1/16W 5.6K 1%
IC
IC1 3132-6711+0-20 IC DSP TC94A73MFG
IC10 3132-6761+0 IC MEMORY EPROM
IC3 3132-6740+0 IC REGULATOR TA48015F
IC5 3132-7331+0 IC MCU TMP92FD28A
Location Part Number Description
