NAD C 565BEE - Page 50

- 50 -
IC77 3132-2821+0 IC LM1117S-3.3
IC8 3132-6720+0 IC REGULATOR TA4805F SMD
U2 3132-3231+0 IC MOTOR DRV W/3.3V REG
MISCELLANEOUS
IC5 3000-9812+0 BLANK LABEL (5X10)
IC5-A 312A-0520+01
SOFTWARE SERVO MCU V4.0 D
J3 2101-3102+0 CONNECTOR FFC 16PIN P1.0
L1 1803-0055+0 INDUCTOR CHIP 10UH
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film, RWR-Wirewound Metal Oxide.
Location Part Number Description
