NAD C 568 User Manual

INTRODUCTION
GETTING STARTED
UNPACKING AND SETUP
WHAT’S IN THE BOX
Packed with your C 568 you will nd:
• An audio cable connector
• The CD 9 remote control with two AA batteries
• A detachable AC power cord
• Quick Setup Guide
SAVE THE PACKAGING
Please save the box and all of the packaging in which your C 568 arrived.
Should you move or otherwise need to transport your C 568, this is by far
the safest container in which to do so. We’ve seen too many otherwise
perfect components damaged in transit for lack of a proper shipping
carton, so please: Save that box!
CHOOSING A LOCATION
Choose a location that is well ventilated (with at least several inches to both
sides and behind), and that will provide a clear line of sight, within 23 feet/7
meters, between the C 568’s front panel and your primary listening/viewing
position. This will ensure reliable infrared remote control communications.
The C 568 generates a modest amount of heat, but nothing that should
trouble adjacent components. It is perfectly possible to stack the C 568 on
top of other components.
NOTE ON INSTALLATION
IMPORTANT! Install the C 568 Compact Disc player on a level, vibration-
free surface. Severe vibration or operation in a tilted position may cause
the player to mis-track. The player may be stacked with other stereo
components, as long as there is adequate ventilation around it. If the C 568
is placed in close proximity to a radio tuner (AM or FM), a VCR or a television
set, the operation of its digital circuits may produce static that would
interfere with reception of weak broadcast signals. If this occurs, move the
C 568 away from other devices or switch it o when viewing or listening to
broadcasts.
QUICK START
In case you simply cannot wait to experience the performance of your new
NAD C 568, we provide the following “Quick Start” instructions to get you
underway.
Please make all the connections to your C 568 with the unit unplugged. It is
also advisable to power down or unplug all associated components while
making or breaking any signal or AC power connections.
PLAY A CD
1 Connect a twin RCA-to-RCA lead from the L (left) and R (right) Line
Output jacks to the corresponding CD inputs on your amplier.
2 Connect the AC cord to the C 568’s AC Mains input and then plug into
an AC outlet. The Standby LED indicator embedded around the bezel of
the STANDBY button will illuminate amber.
3 Press the STANDBY button to turn ON the player. The Standby LED
indicator will turn from amber to blue and illuminate the Vacuum
Fluorescent Display (VFD).
4 Press [STOP/OPEN] to open the disc drawer.
5 Place a CD, label side up, in the tray’s circular recess. Be certain that the
disc is centered within the recess.
6 Press [PLAY/PAUSE/SKIP]. The drawer closes automatically, and the disc
begins to play.
7 At any time you may rotate the [PLAY/PAUSE/SKIP] knob to select
dierent tracks on the disc.
8 Press [PLAY/PAUSE/SKIP] if you want to stop play temporarily while
keeping the pickup at its current position on the disc.
Press [PLAY/PAUSE/SKIP] again when you want to resume playback.
Press [STOP/OPEN] if you want to end play and reset the pickup to the
beginning of the disc.
5
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

NAD C 568 Specifications

General

Display type	VFD
Device type	Portable CD player
MP3 playback	-
Product color	Black
Pause function	Yes
Playback modes	Random, Repeat, Repeat all
Disc loading type	Tray
Channel separation	90 dB
Disc playback modes	Random, Repeat all, Repeat track
Playback disc types	CD, CD-R, CD-RW
Digital audio optical out	1
Power source type	AC
Power consumption (typical)	0.5 W
Signal-to-Noise Ratio (SNR)	118 dB
Total Harmonic Distortion (THD)	0.01 %
Package weight	6900 g
Playback disc formats	CD audio

Weight and Dimensions

Depth	306 mm
Width	435 mm
Height	80 mm
Weight	4900 g
