NAD c390dd - Electrical Parts List; IC

IC
03-02985-33 Ragulator LP2985-33DBVR U6023
03-01117-01 Linear Regulator LM1117MPX-5.0/NOPB/ AMS1117-5.0 U6000
03-05532-03 Dual OPAMP NE5532DR SOIC8 U6004, U6007, U6008, U6009
03-01804-01 A/D Converter PCM1804DBR U6005
03-02134-00 Dual OPAMP OPA2134UA/2K5E4 SO-8 U6010
03-02611-01 Power converter LM2611BMF,SOT23-5 U6013
03-00595-01 Shift Register SN74HC595D/74HC595D/MM74HC595M U6015
03-00138-05 3 TO 8 LINE DECODER 74HC138D U6016
or 03-00138-02 Line Decoder MM74HC138M U6016
03-00084-02 Quad OPAMP TL084BCD U6017
03-01195-01 Audio Attenuator NJW1195V U6006
03-00244-01 Octal Buffer 74LCX244 U6014
03-00714-01 UHS Dual Inverter with Schmitt Trigger Inputs NC7WZ14P6X U6018, U6019
03-74901-01 Regulator TPS7A4901DGNR U6021
03-73001-01 Regulator TPS7A3001DGNR U6022
Diode
33-20004-01 Zener Diode S1GM4 SMA D6000
33-40054-00 Schottky Diode BAT54S, SOT23 D6001, D6002, D6003, D6004
33-40352-01 Switch Diode 1SS352(TPH3,F),1SS355TE-17 D6005, D6006, D6014, D6015, D6018, D6019, D6020, D6021, D6022
33-44148-17 Switch Diode 1N4148W-NR D6007, D6013
33 30560 01
DIODE SCHOTTKY
MBR0560 TP
D6009
33
-
30560
-
01
DIODE
SCHOTTKY
MBR0560
-
TP
D6009
Transistor
31-01815-03 Transistor C1815, SOT23 Q6026, Q6126
31-01015-03 Transistor A1015, SOT23 Q6025, Q6125
31-00114-05 Digital transistor DTC114EKA Q6017
Inductor
08-04100-08 Power Inductor 10uH,MSS7341-103ML L6030
08-04331-06 Ferrite Bead SMD 742792037, 330ohm@100MHz, ±25%, 2A L6000, L6005, L6006, L6016, L6026
08-04301-04 Ferrite Bead SMD 742792035, 300ohm@100MHz, ±25%, 0.3A L6100
Capacitor
26-10051-00 Ceramic Chip Capacitor 10pJ,50V,0603,NPO C6125
26-33151-00 Ceramic Chip Capacitor 330pJ,50V,0603,NPO C6104
26-47351-00 Ceramic Chip Capacitor 47nK,50V,0603,X7R C6123, C6124
26-10421-10 Cermatic Chip Capacitor 100nK,25V 0603,X7R
C6000, C6029, C6030, C6034, C6041,C6102, C6111, C6129, C6130,
C6183
26-33051-01 Ceramic Chip Capacitor 33PJ,50V,0805,NPO C6064, C6131, C6122, C6054
26-10151-01 Ceramic Chip Capacitor 100pJ,50V,0805,NPO
C6016, C6027, C6039, C6050, C6300, C6301, C6100, C6107, C6108,
C6109
26-18151-01 Ceramic Chip Capacitor 180pJ,50V,0805,NPO C6028, C6047
26-56151-01 Multilayer Ceramic CAP 560pJ,50V,0805,NPO C6019, C6037, C6043, C6053
26-10212-01 ceramic capacitor 1nJ,100V,0805,NPO C6192, C6193,
26-15251-11 Ceramic Chip Capacitor 1n5J,50V,0805,NPO C6024, C6049
26-10351-01 Cermatic Chip Capacito 10nK,50V,0805,X7R C6191, C6194, C6195, C6196
26-10421-01 Ceramic Chip Capacitor 100nK,25V,0805,X7R
C6008, C6025, C6032, C6042, C6199, C6200, C6204, C6205,
C6206,C6068, C6069, C6070, C6071, C6072, C6081, C6082, C6083,
C6084, C6085, C6116, C6117, C6182
26-22451-11 Cermatic Chip Capacito 220nK,50V,0805,X7R C2012X7R1H224KT C6089, C6090
26-22511-01 Ceramic Chip Capacitor 2u2F,16V 0805, X7R C6088,C6087, C6091,C6092
26-47521-11 Ceramic Chip Capacitor 4.7uK,25V,X5R,0805,C2012X5R1E475KTJ00E C6197, C6198
26-10611-11 Ceramic Chip Capacitor 10uFK,10V,X5R,0805,C2012X5R1A106KT C6002, C6006
26-22660-11 Ceramic Chip Capacitor 22uF, 6.3V, X5R, 0805 C6005, C6026
26-10521-22 Ceramic Chip Capacitor 1uF, 10%, 25V,X7R,1206 C6101
26-10621-12 Ceramic Capacitor SMD 10uF, 25V, X5R, 1206, C3216X5R1E106KT C6009
26-10621-12 Ceramic Chip Capacitor 10uF, 25V, X5R, 1206, C3216X5R1E106KT C6004, C6086, C6093, C6095, C6096, C6106, C6207, C6208
C390DD BOM
ELECTRICAL PARTS LIST
