NAD c390dd - Vfd Display

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
07-90102-01 Chip Resistor 1K,0805,1/8W,±5%,RC0805JR-071KL R3025
07-91201-01 Chip Resistor 1.2K,0805,1/8W,±1%,RC0805FR-071K2L R3056, R3057
07-90103-01 Chip Resistor 10K,0805,1/8W,±5%,RC0805JR-0710KL R3022, R3029
07-90223-01 Chip Resistor 22K,0603,1/10W,±5%,RC0805JR-0722KL R3047
07-94702-01 Chip Resistor 47K,0805,1/8W,±1%,RC0805FR-0747KL R3049
07-90471-02 Chip Resistor 470,1206,1/4W,±5%,RC1206JR-07470RL R3016
07-90223-02 Chip Resistor 22K,1206,1/4W,±5%,RC1206JR-0722KL R3001
07-90470-03 Chip Resistor 47,1210,1/4W,±5%,RC1210JR-0747RL R3048
07-90151-03 Chip Resistor 150,1210,1/2W,±5%,RC1210JR-07150RL R3055
07-90121-10 Chip Resistor Network 120,0603x4,1/10W,±1% R3004, R3006, R3011, R3013
07-90103-00 Chip Resistor 10K,0603,1/10W,±5%,RC0603JR-0710KL
R3030, R3031, R3032, R3033, R3039, R3040,
R3041, R3042
Resistor
07-20000-51 Chip Resistor 0,1/4W,±5% R3034, R3037
Switch
11-04101-05 TACT SW IT-1102A-1160
K3000, K3001, K3002, K3003, K3004, K3005,
K3006, K3007
IC
03
-
00141
-
00
IR Receiver
GP1UXC41QS
U3000
03
-
00141
-
00
IR
Receiver
GP1UXC41QS
U3000
Diode
33-50565-12 Photo-Diode
㪱󰿎㑶 BL-BB3JCUB2C4V-1-10F 㪱ܝ⊶䭓㣗ೈ
D3005
Capacitor
06-10121-12 Alu Electrolytic Capacitor
CD284,100uF,25V,±20%,105ć,F5.0
C3016
06-47012-03 Alu Electrolytic Capacitor CD284,47uF,100V,±20%,F5.0 C3035
06-22111-33 Alu Electrolytic Capacitor CD284,220uF,16V,±20%,F2.5 C3022, C3023
06-47111-12 Alu Electrolytic Capacitor CD263,470uF,16V,±20%,F5.0 C3043
Connector
23-00128-02 VFD DISPLAY
CIG128X3201(ⷁ㝓)
U3001
75-230001-0 VFD Cover Sheet PC Black UL94V-0 T=0.45mm
⫼12mmᆑ3Mঠ䴶㛊䌈Ѣᰒ⼎ሣϞ
67-048002-0 IR Bracket
Tin plated ༈䚼஋咥ⓚ
66-048002-0 IR Bracket Tin plated
13-22504-05 Connector Socket XHB 2 .5A-4AW J3002
13-12505-14 Connector
2.54mm䯈䎱, 5Pin,
CNT-M254-1*5-GS-5.9/3-N
CON3000
14-39024-10 Connector Wire
2.0mm䯈䎱, 24Pin, L=250mm, CNT-C200-24-250
J3010
01-39014-00 Encode BOARD
PCB
A16-39014-21 C390DD Encode PCB
Resistor
07-91002-00 Chip Resistor 10K,0603,1/10W,±1% R3145, R3146
07-90103-00 Chip Resistor 10K,0603,1/10W,±5% R3044, R3045
26-10611-01 Ceramic Chip Capacitor 10uF,0805,10V,C0805C106M8PACTU C3029
26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R,±10% C3030, C3031
ENCODE
J37-16243-00 ENCODE EC16B243040F S3000
01-39004-00 SPDIF BOARD
PCB
A16-39004-23
C390DD SPDIFǂPCB
