REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
C001 67-230004-0 Chassis 1 R001 67-230001-1C Rear Panel 1
C002 67-230008-0 Connector Bracket 1 R002 67-230010-0A Audio Cover 1
C003 75-049001-0 Spacer Support 2 R003 67-230009-0A HDMI Cover 1
C004 85-151002-0 PCB Guide 3 R004 71-003001-1 Grd.Post Bolt 1
C005 75-124001-0 Foot 4 R005 71-003002-0 Grd.Post Cap 1
C006 78-001002-0 Foot Pad 4 R006 17-03001-16 Binding Post(Red) 4
C007 69-112002-0 Copper Spacer 4 R007 17-03001-17 Binding Post(Black) 4
C008 01-39010-00 PSU Board A 1 R008 A17-07103-26 AC Inlet 1
C009 78-230002-0 Insulation sheet 1 R009 A11-01101-03 Rocker Switch 1
C010 01-39011-00 PSU Board B 1 R010 67-230007-0A USB Fasica 1
C011 01-39001-00 Main Board 1 R011 76-230002-0 Insulation Pad 1
C012 01-39009-00 Powamp Board 1 R012 85-127002-0 Plastic Rivet 5
R013 01-39007-00 USB Board 1
R014 01-39002-00 SPK Board 1
F001 70-230002-1B Fascia 1 R015 01-39005-00 INT Board 1
F002 70-230004-0 End Cap L 1 R016 01-39004-00 SPDIF Board 1
F003 70-230003-0 End Cap R 1
F004 67-230003-0 Subfascia 1
F005 77-230003-0 Power Button Bezel 1 T001 67-230002-0 Top Cover 1
F006 J71-124001-0 Power Button 1
F007 77-230004-0 Cursor Frame Bezel 1
F008 J71-230001-0 T747 Cursor 1 S001 61-022205-5 Self Tapping Screw BTB2.5x5 2
F009 77-230001-0 USB Bezel 1 S002 61-023106-0 Self Taping Screws STB3×6 36
F010 66-230001-0 Lens Bracket 3 S003 61-023206-0 Self Taping Screws BTB3×6 21
F011 76-230001-0 VFD Lens 1 S004 61-373506-0 Machine Screw M3×6 12
F012 77-223001-0 2P Input Button Bezel 1 S005 61-023108-0 Self Taping Screws STB3×8 4
F013 J71-124002-0 2P Input Button 1 S006 61-023208-0 Self Taping Screws BTB3×8 16
F014 J71-223001-0 Volume Knob 1 S007 61-073108-0 Self Taping Screws STO3×8 2
F015 77-230002-0 Volume Knob Bezel 1 S008 61-084108-0 Self Taping Screws STPW4X8 4
F016 75-230001-0 VFD Cover Sheet 1 S009 63-040506-1 Serrated Lock Washer 8
F017 01-39003-00 FPP Board 1 S010 63-010408-3 Plain Washer Ø4 1
F018 01-39013-00 Bootload Board 1 S011 63-040408-0 Spring Washer 1
F019 01-39014-00 Encode Board 1 S012 62-010402-0 Nut 1
F020 02-39099-00 Fascia Assembly Complete 1
EXPLODED VIEW PARTS LIST
To Next Page
