NAD c390dd - Page 20

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
IC
03-00734-01 Buffer NC7NZ34K8X U4006
03-00716-01 Buffer NC7WZ16P6X U4005, U4007
03-01117-18 Regulator LM1117MPX-1.8/AMS1117-1.8 U4003
03-07125-01 BUFFER NC7SZ125P5X U4002, U4004, U4008
03-01117-33 Regulator LM1117MPX-3.3/AMS1117-3.3 U4001
03-04192-01 SPDIF interface DIX4192IPFB U4000
03-00006-01 VERY LOW CAPACITANCE ESD PROTECTION USBLC6-2SC6 D4002, D4003, D4005
Diode
33-40352-01 Switch Diode 1SS352(TPH3,F),1SS355TE-17 D4000, D4001, D4010, D4011, D4012, D4013
Transistor
31-00114-05 Digital transistor DTC114EKA Q4000
Inductor
08-04609-01 Ferrite Bead SMD BEAD,600 OHM@100MHZ,0.5A,0805 L4000, L4001, L4002
Capacitor
26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R,±10%
C4006, C4011, C4016, C4017, C4018, C4021,
C4024, C4027, C4028, C4035, C4040, C4102,
C4103, C4104
26
-
10251
-
11
Ceramic Chip Capacitor
1nJ 50V 0805 NPO
C4000 C4008
26
-
10251
-
11
Ceramic
Chip
Capacitor
1nJ
,
50V
,
0805
,
NPO
C4000
,
C4008
26-10351-11 Ceramic Chip Capacitor 10nJ,50V,0805,NPO C4004, C4012, C4065, C4100, C4101
26-10411-01 Ceramic Chip Capacitor 100nK,16V,0805,X7R C4007, C4014, C4031
26-10451-11 Ceramic Chip Capacitor 100nK,50V,0805,X7R,±10%
C4001, C4002, C4003, C4005, C4013, C4025,
C4026, C4032, C4033, C4034, C4036, C4037,
C4038
26-22660-11 Ceramic Chip Capacitor 22U,6.3V,±10%,X5R, 0805
C4009, C4015, C4020, C4022, C4023, C4029,
C4030
Resistor
07-90000-00 Chip Resistor 0R R4012, R4018
07-94708-00 Chip Resistor 4.7,0603,1/10W,±1%,RC0603FR-074R7L R4032
07-93309-00 Chip Resistor 33,0603,1/10W,±1%,RC0603FR-0733RL R4006, R4009, R4033
07-99319-00 Chip Resistor 93.1,0603,1/10W,±1%,RC0603FR-0793R1L R4027
07-91000-00 Chip Resistor 100,0603,1/10W,±1%
R4002, R4003, R4004, R4014, R4015, R4022,
R4023, R4025, R4026, R4028, R4030, R4031
07-91100-00 Chip Resistor 110,0603,1/10W,±1%,RC0603FR-07110RL R4001
07-92050-00 Chip Resistor 205,0603,1/10W,±1%,RC0603FR-07205RL R4024, R4029
07-94701-00 Chip Resistor 4.7K,0603,1/10W,±1% R4020
07-91002-00 Chip Resistor 10K,0603,1/10W,±1% R4017
07-94708-01 Chip Resistor 4.7,0805,1/8W,±1%,RC0805FR-074R7L R4010, R4013
07-90100-01 Chip Resistor 10,0805,1/8W,±5%,RC0805JR-0710RL R4008, R4100, R4101
07-93309-01 Chip Resistor 33,0805,1/8W,±1%,RC0805FR-0733RL R4019, R4021
07-97509-01 Chip Resistor 75,0805,1/8W,±1%,RC0805FR-0775RL R4005, R4007
07-91000-01 Chip Resistor 100,0805,1/8W,±1% R4000
07-91002-01 Chip Resistor 10K,0805,1/8W,±1%,RC0805FR-0710KL R4034
