NAD c390dd - Page 21

∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
Capacitor
06-10121-12 Alu Electrolytic Capacitor
CD284, 100uF, 25V, ±20%, 105ć, F5.0
C4019
Connector
03-00147-01 Optical Receive TORX147L(25M,F,T) OP4000, OP4001
03-01180-01 Light Transmitting DLT1180A-2(25M) OP4002
J17-09003-28 Mic Connector NC3FAAH2 J4000
17-01003-16 3RCA AV3-8.4-13B/EL J4001
22-82020-01 Common Inductor T8-20/20-1.8mH T4001, T4002, T4003, T4004
01-39005-00 INT BOARD
PCB
A16-39005-23 C390DD INT PCB
IC
03-03221-02 RS232 Interface MAX3221CAE+/MAX3221CDBR/MAX3221EEAE U5001
03-00717-01 Buffer NC7WZ17P6X U5000
Diode
33-44148-17 1N4148W-NR,SOD123 1N4148 D5000, D5001
33-14709-10 Zener Diode 4V7,1/2W, LL34 D5002, D5003, D5015
33-40352-01 Switch Diode 1SS355TE-17
D5004, D5005, D5006, D5007, D5008, D5009,
D5014
33-11200-11 Zener Diode SMD 12V,1/2W, LL34 D5010, D5011, D5012, D5013
Capacitor
26-47351-00 Ceramic Chip Capacitor 47nK,50V,0603,X7R C5003
26-10411-00 Ceramic Chip Capacitor 100nF,16V 0603, X7R,±10% C5000, C5002, C5004, C5011, C5013, C5018
26-47421-00 Ceramic Chip Capacitor 470nZ,25V,0603,Y5V C5009, C5015, C5016
26-22051-01 Ceramic Chip Capacitor 22PJ,50V,0805,NPO C5005, C5017
26-10151-11 Low ESL Feed Through
CKD510X5R1H101ST/NFM21CC101U1H3
0805,X5R,100p,50V
C5012, C5014
26-22151-01 Ceramic Chip Capacitor 220pF,50V,0805, 10%, X7R C5019, C5021
26-10411-01 Ceramic Chip Capacitor 100nK,16V,0805,X7R C5006
26-22660-11 Ceramic Chip Capacitor 22U,6.3V,±10%,X5R, 0805 C5001, C5008, C5010
Resistor
07-90121-00 Chip Resistor 120,0603,1/10W,±5%,RC0603JR-07120RL R5006, R5008, R5015
07-91001-00 Chip Resistor 1K,0603,1/10W,±1%,RC0603FR-071KL R5019
07-92201-00 Chip Resistor 2.2K,0603,1/10W,±1%,RC0603FR-072K2L R5005
07-90472-00 Chip Resistor 4.7K,0603,1/10W,±5%,RC0603JR-074K7L R5020
07-96801-00 Chip Resistor 6.8K,0603,1/10W,±1%,RC0603FR-076K8L R5011
07-91002-00 Chip Resistor 10K,0603,1/10W,±1%,RC0603FR-0710KL R5003, R5007, R5009, R5010
07-93908-01 Chip Resistor 3.9,0805,1/8W,±1%,RC0805FR-073R9L R5000, R5002
07-91009-01 Chip Resistor 10,0805,1/10W,±1%,RC0805FR-0710RL R5001, R5004, R5013, R5014
07-94709-01 Chip Resistor 47,0805,1/8W,±1%,RC0805FR-0747RL R5017, R5018
07-91000-01 Chip Resistor 100,0805,1/8W,±1% R5012, R5016
Connector
13-21015-01 FPC Connector SMD 15Pin,1.0-9-15PWB J5002
Transistor
