C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
31-01220-00 Power Transistor KSA1220AYSTU, TO-126 Q5000
Capacitor
06-10121-02 Alu Electrolytic Capacitor
CD263(X),100uF,25V,±20%,105ć,F5.0
C5007
Connector
13-22504-20 Connector Socket XHB2.5A-4A, Gold plated SIP4A J5010
17-08009-00 RS232 Socket RS232/F,7906-09FHA J5004
17-02002-09 Phone Jack SCJ351P00WS0BP6G J5001
17-01002-03 2RCA *2 holes RJ-21V01 J5005
17-02001-04 3.5mm phone jack ST-323B-04 / CKX-3.5-02-3P J5008
01-39007-00 USB BOARD
PCB
A16-39007-21 C390DD USB PCB
IC
03-04160-01 DC/DC CONVERTER ADUM4160BRWZ U7013
03-00151-33 Linear Regulator ADP151AUJZ-3.3-R7 U7016
03-02021-01 POWER-DISTRIBUTION SWITCHES TPS2021D U7005
03-48162-03 SDRAM MT48LC16M16A2P-75:D U7000
03-01020-01 USB Streaming Controller TAS1020BPFB U7012
03-03825-33 RESET TPS3825-33DBVT U7007
03-01963-33 Linear Regulator TL1963A-33KTTR U7001
orN03-38500-33 Linear Regulator LP38500-3v3 U7001
03-54331-01 DC/DC CONVERTER TPS54331D U7002
03-02464-13 BUS EEPROM 24LC64-I/SN U7009
03-02464-02 BUS EEPROM 24LC64-I/SN U7009
03-00032-03 MCU AT32UC3A0512-ALUT U7003
03-00221-02
High-Speed USB 2.0 (480 Mbps) 1:2 Multiplexer/Demultiplexer
Switch With Single Enable
TS3USB221ARSER U7006
03-00714-01 TinyLogic. UHS Dual Inverter with Schmitt Trigger Inputs NC7WZ14P6X U7008
03-00244-07 Octal Buffer SN74AHC244PW U7010, U7011
03-29800-01 CMOS SINGLE VOLTAGE 3V ONLY FLASH MEMORY MX29LV800CBTI-70G U7018
Diode
33-50805-45 LED(yellow green) L-C170KGCT EC04-0805GC D7001
33-20336-01 SCHOTTKY DIODE SMD SS36, SCHOTTKY,60V D7000
33-00502-01 ESD Protection diode PRTR5V0U2X,215 D7002
33-40352-01 Switch Diode 1SS355TE-17 D7006, D7007, D7008, D7009, D7010, D7011
Crystal
04-11202-05 CRYSTAL
12MHz, CL=20pF, ±30ppm, IB-F-12.000M-20-
3050-2070
XC7001
04-16000-01 CRYSTAL 6.000000 MHZ HCM49,HCM49-6.000MABJT XC7002
04-22452-06 VCXO 24.576MHz, C3391-24.576MHz,SMD 5*7 U7014
or 04-22452-09 Oscillator SRTD3T-24.576MHZ TR U7014
04-22252-03 VCXO 22.5792MHz, C3398-22.579200MHz,SMD 5*7 U7015
or 04-22252-05 Oscillator SRTD3T-22.5792MHZ TR U7015
