NAD c390dd - Page 13

78-015002-0 Transistor Washer TW-5
78-013008-1 Insulated Cushion SQ9418, SPK-4
PCB
A16-39008-21 C390DD Phono PCB C390DD Phono PCB
Transistor
31-00114-05 Digital transistor DTC114EKA Q9518, Q9519
Diode
33-44148-17 Switch Diode 1N4148W-NR D9500, D9501
Capacitor
26-10151-02 ceramic capacitor 100pJ,50V,1206,NPO C9503, C9510, C9528, C9535
26-18151-01 ceramic capacitor 180pJ,50V,0805,NPO C9505, C9508, C9530, C9533
26-82151-01 ceramic capacitor 820pJ,50V,0805,NPO C9506, C9531
26-10212-01 ceramic capacitor 1nJ,100V,0805,NPO C9544, C9545, C9546, C9547
26-10421-01 ceramic capacitor 100nK,25V,0805,X7R C9501, C9513, C9518, C9520, C9521, C9523, C9526, C9538
Resistor
07-98209-92 MELF Resistors MMF204FRE82R,82,1/4W,±1% R9514, R9542
07-91000-92 MELF Resistors MMF204FRE100R,100,1/4W,±1% R9512, R9540
07-92200-92 MELF Resistors MMF204FRE220R,220,1/4W,±1% R9501, R9523, R9529, R9551
07-92550-92 MELF Resistors MMF204FRE255R,255,±1% R9519, R9547
07-95600-92 MELF Resistors MMF204FRE560R,560,1/4W,±1% R9506, R9534
07-95900-92 MELF Resistors MMF204FRE590R,590,1/4W,±1% R9500, R9522, R9528, R9550
07-91102-92 MELF Resistors MMF204FRE11K,11K,1/4W,±1% R9516, R9544
07-91302-92 MELF Resistors MMF204FRE13K,13K,1/4W,±1% R9553, R9557
07-92402-92 MELF Resistors MMF204FRE24K,24K,1/4W,±1% R9552, R9556
07-94702-92 MELF Resistors MMF204FRE47K,47K,1/4W,±1% R9504, R9518, R9532, R9546
,,,
,,,
07-96802-92 MELF Resistors MMF204FRE68KR, 68K,±1%,1/4W R9510, R9511, R9538, R9539
07-91333-92 MELF Resistors MMF204FRE133K,133K,1/4W,±1% R9515, R9543
07-93300-01 Chip Resistor 330,0805,1/8W,±1%,RC0805FR-07330RL R9508, R9536
07-94700-01 Chip Resistor 470,0805,1/8W,±1%,RC0805FR-07470RL R9517, R9545
07-91001-01 Chip Resistor 1K,0805,1/8W,±1%,RC0805FR-071KL R9524, R9525, R9526, R9527
07-93001-01 Chip Resistor 3K,0805,1/8W,±1%,RC0805FR-073KL R9502, R9521, R9530, R9549
07-91602-01 Chip Resistor 16K,0805,1/8W,±1%,RC0805FR-0716KL R9503, R9520, R9531, R9548
07-92202-01 Chip Resistor 22K,0805,1/8W,±1%,RC0805FR-0722KL R9554, R9555
07-94702-01 Chip Resistor 47K,0805,1/8W,±1%,RC0805FR-0747KL R9513, R9541
IC
03-05532-00
Dual Op Amp NE5532P DIP8
U9500
Resistor
07-22709-50
Metal Film Resistor 27,1/6W,±1%
R9507, R9535
07-23900-50
Metal Film Resistor 390,1/6W,±1%
R9505, R9533
Inductor
A08-01101-01 Inductor(Coil)
100uH,±20%, EMC421-121NS, Pitch=5mm
L9500, L9502
08-01372-00 Inductor(Coil)
TL-372,3.7mH, ±10%
៤ൟ䎼䎱5mm
L9501, L9503
Relay
12-02202-15 Signal Relay HFD31/5 5VDC RL9500, RL9501
7UDQVLVWRU
31-02240-00 Transistor 2SC2240-GR(TPE2,F) TO-92 Q9500, Q9502, Q9503, Q9506, Q9508, Q9510, Q9512, Q9513, Q9516
31-00970-00 Transistor 2SA970-GR(TPE2,F) TO-92 Q9501, Q9504, Q9505, Q9507, Q9509, Q9511, Q9514, Q9515, Q9517
Capacitor
06-10111-25 Alu Electrolytic Capacitor
EEUFC1C101H,100uF,16V,±20%,105ć
C9502, C9514, C9517, C9519, C9522, C9524, C9527, C9539, C9598,
C9599
06-10111-42 Alu Electrolytic Capacitor
EEUFC1C101H,100uF,16V,±5%,105ć(⬅06-10111-
25ߚ䗝)
C9515, C9540
06-10111-25 Alu Electrolytic Capacitor
EEUFC1C101H,100uF,16V,±20%,105ć
C9515, C9540
06
-
10111
-
28
ALU Electrolytic CAP
UKW1A101MDDTA, 100uF,10V,±20%,85
ć
C9504, C9509, C9529, C9534
C390DD BOM
