∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
INDUCTOR
08-05100-01 INDUCTOR 10UH L5
08-04338-00 INDUCTOR LQM21NNR33K10D,0.33uH L1
08-04158-00 Inductor SMD 150nH 744302015 L2, L3
08-04727-00 Inductor SMD 72nH 744302007 L4_CHLF, L4_CHRF
08-04100-24 Inductor SMD 74477410,10uH L12
08-04609-01 BEAD CBY201209A601T L6, L7, L8
08-04102-16 BEAD 1000,±25%,100MHz,0603 742792664 L9
CONNECTORS
04-11083-01 Oscillator SMD MXU510P20-3-B20-2L-MJT-108Mhz X1
TRANSISTORS
31-05620-00 MOSFET IRFB5620PbF Q301_CHL, Q301_CHR, Q303_CHL, Q303_CHR
RESISTOR
07-40107-00 Cement Resistor RGC3, 0.01, 3W, ±5%, Pitch=9mm R142_CHLF, R142_CHRF
07-30220-05 Metal Oxide Film Resistor
RY21-3,22,3W,±5%,䭓ᓩ㒓
R140_CHLF, R140_CHRF, R141_CHLF,
R141_CHRF
CAPACTIOR
25-10322-02 Metallized Polyester Film Capacitor CL23B-250V-103J RA C173_CHLF, C173_CHRF
25-22412-00 Metallized Polyester Film Capacitor 220nF, 100V, 10% C177_CHLF, C177_CHRF
25-33412-04 Metallize Polypropylene Capacitor MKP2,330nF / 100V C176_CHLF, C176_CHRF
25-47222-02 Film capacitor 4.7nF,250V,±1% C170_CHLF, C170_CHRF
06-10951-06 Alu Electrolytic Capacitor CD263(X),1uF,50V,±20%,F2.5 C182_PSL, C182_PSR, C184_PSL, C184_PSR
06-22011-10 ALU Electrolytic Capacitor
22uF, 16V, ±20%, 105ć
C179_PSL, C179_PSR
06-47061-01 ALU Electrolytic Capacitor
47uF, 63V, ±20%, 85ć
C63, C123
06-33121-06 Alu Electrolytic Capacitor CD289,330uF,25V,±20% C138, C153
06-33160-07 Alu Electrolytic Capacitor
PLF0J331MDL4TD,330uF,6.3V,±20%,105ć,F2.5
C126
06-10111-21 Alu Electrolytic Capacitor
CD284,100uF,10V,±20%,105ć,F2.5
C47
06-10111-22 Alu Electrolytic Capacitor
CD289,100uF,16V,±20%,105ć,F2.5
C55, C151
06-10111-05 ALU Electrolytic Capacitor
100uF, 16V, ±20%, 85ć
C62
06-10211-13 Electrolytic Capacitor
CD284,1000uF,10V,±20%,105ć,F3.5
C59
06-47281-04 ALU Electrolytic Capacitor
4700uF, 80V, ±20%, 85ć, ϸা㛮
C28, C30, C40, C41
INDUCTOR
22-01626-00 Transformer T16*9*5-4TS L14_CHLF, L14_CHRF
08-01509-00 Inductor
5uH, ±30%, T44-2 (Ø0.5mmⱘ㒓㒩ࠊ26೜)
L10_CHLF, L10_CHRF
J19-00442-00 Ferrite Ring T44-2 L10_CHLF, L10_CHRF
08-01140-00 Inductor 14.5uH, ±20%, T106-2-33TS L13_CHLF, L13_CHRF
J19-01062-00 Ferrite Ring T106-2 L13_CHLF, L13_CHRF
08-01330-00 Inductor 744132,33uH L11
CONNECTORS
21-10750-00 Link(1.0) L=7.5mm J10, J11
12-02202-15 RELAY POWER HFD31/5 5VDC RL1
12-03101-16 RELAY POWER HF115F/012-2HS4A RL2, RL3
A07-70022-19 SPST Switch
ST-22 90ć W TYPE 䬔䫵
J8
