NAD c390dd - Page 35

33-20336-01 Schottky Rectifier Diode SS36 D410, D412, D423
33-20054-03 Schottky Diode BAT54 D422
Inductor
08-04221-01 Ferrite Bead SMD 220R @100Mhz, CBG201209U221 FB410, FB411, FB412, FB413, FB414, FB415, FB416, FB417, FB401, L401
08-04100-08 Power Inductor 10uH,MSS7341-103ML L402
Crystal
04-12864-01 Crystal 28.63636MHZ CL=22pF ,FL=20PPM Y403
IC
03-07623-01 HDMI Transceiver ADV7623 U419
03-24256-12 MCU
PIC24FJ256GA106-I/PT(C390DD⿟ᑣ)
U415
03-24256-02 MCU PIC24FJ256GA106-I/PT U415
03-00524-03 ESD Production IC RClamp0524PA U401, U402, U403, U404, U405, U406, U407, U408, U409, U410, U411, U412
03-01963-18 Regulator TL1963A-18KTTR U445
03-01963-33 Regulator TL1963A-33KTTR U444
03-54331-01 DC/DC CONVERTER TPS54331D U416
03-03825-33 Supervisory Circuit TPS3825-33DBVT,SOT23-5 U414
03-01117-06 Linear Regulator AMS1117-3.3 U413
03-00244-01 Octal Buffer 74LCX244WM/MC74LCX244DW/SN74LVC244ADW U417
CONNECTORS
17-08119-04 HDMI SOCKET HDMI-007 P401, P402, P403, P408
06-33160-01 Alu Electrolytic Capacitor
HCN,330uF,6.3V,±20%,105ć,F3.5, 8×11.5mm
B403, B404
06-10260-11 Alu Electrolytic Capacitor
HPE,1000uF,6.3V,±20%,105ć,F5.0
C486
∝ḥ(Ҁ)⾥ᡔ᳝䰤݀ৌ
ᑣ߫ো˖HS40-C390DD_B17VM1.4
C390DD BOM
⠜ᴀ˖VM1.4
⫼䗨˖for MP
᮹ᳳ˖2012-03-19
