NAD C715 Service Manual

2-2
IC BLOCK DIAGRAMS & PIN DESCRIPTION
74HC4066D
Quad bilateral switche
handbook, halfpage
MGR257
11
4Y
12
4E
4Z
10
3Z
9
2Z
3
1Z
2
8
3Y
6
3E
4
2Y
5
2E
1
1Y
13
1E
Fig.5 Functional diagram.
handbook, halfpage
MGR258
V
CC
GND
nE
nZ
nY
V
CC
Fig.6 Schematic diagram (one switch).
74VHC08TTR
PIN CONNECTION AND IEC LOGIC SYMBOLS

NAD C715 Specifications

General

Frequency range	80 - 22000 Hz
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.15 %
Digital tuner	Yes
Supported radio bands	AM, FM
Device type	Portable CD player
Product color	Black
Disc loading type	Tray
Channel separation	78 dB
Number of optical discs	1 discs
Volume control	Rotary
Video in	1
Package depth	116 mm
Package height	362 mm
Package weight	6000 g

Weight and Dimensions

Depth	324 mm
Width	213 mm
Height	103 mm
Weight	4500 g
