NAD C715 Service Manual

1-5
SPECIFICATIONS (C715)
AMPLIFIER SECTION
Power output Stereo Mode 25W (6 ohms within rated distortion, 1kHz)
IHF dynamic power (6 ohms) 28W
Total harmonic distortion at rated power 0.15%
Damping factor (6 ohms) >102
Input sensitivity and impedance (Tape IN) 370mV/27kΩ
Frequency response +1 dB/-3dB (Ref. 1 kHz, 10Hz – 80kHz)
Signal/noise ratio, 95dB (Ref. rated power/ 6 ohms A-WTD)
Signal/noise ratio 80dB (Ref. 1W / 6 ohms A-WTD)
TUNER SECTION
AM SECTION
Tuning range 520kHz - 1710kHz (North America version, 10kHz steps)
522kHz -1629kHz (Europe version, 9kHz steps)
Usable sensitivity 60dBuV
S/N ratio 40dB
Total Harmonic Distortion 1.5%
Selectivity 25dB
Frequency response -6dB (Ref. 400Hz, 80Hz – 2.2kHz)
FM SECTION
Tuning range 87.50MHz – 108MHz (50kHz steps)
Usable sensitivity, MONO 10dBuV
S/N Ratio MONO 60dB
S/N Ratio STEREO 55dB
Total Harmonic Distortion, MONO 0.3%
Total Harmonic Distortion, STEREO 0.5%
Frequency response -3dB (Ref. 1 kHz, 30Hz – 12kHz)
Channel Separation 35dB
RDS decode sensitivity 29dBuV
CD SECTION
Output level 1.16V
Frequency response (ref. 0dB 1kHz, 20Hz-20kHz) +1dB
Total harmonic distortion (ref. 1kHz, VIDEO OUT) 0.04%
Signal/Noise ratio (A-weighted, ref. 1kHz VIDEO OUT) 100dB
Channel balance (ref. 0dB 1kHz) 0.5dB
Dynamic range (A-WTD, VIDEO OUT) 82dB
Channel separation 78dB (1kHz)
78dB (10kHz)
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 213 x 103 x 324 mm (Net)
213 x 116 x 362 mm (Gross)
Net weight 4.5kg
Shipping weight 6.0kg
Note: Gross dimensions include feet, extended buttons and rear panel terminals.
Specications are subject to change without notice. For updated documentation and features, please log onto www.NADelectronics.com for the latest
information about C 715.

NAD C715 Specifications

General

Frequency range	80 - 22000 Hz
Audio formats supported	MP3
Signal-to-Noise Ratio (SNR)	95 dB
Total Harmonic Distortion (THD)	0.15 %
Digital tuner	Yes
Supported radio bands	AM, FM
Device type	Portable CD player
Product color	Black
Disc loading type	Tray
Channel separation	78 dB
Number of optical discs	1 discs
Volume control	Rotary
Video in	1
Package depth	116 mm
Package height	362 mm
Package weight	6000 g

Weight and Dimensions

Depth	324 mm
Width	213 mm
Height	103 mm
Weight	4500 g
