NAD C715 - SECTION 3 ELECTRICAL PARTS LIST; MAIN PCB ASSY (DABC: COP12018 B, C: COP12018 C, AH: COP12018 D)

MAIN PCB ASS'Y
(
DABC : COP12018B, C : COP12018C, AH : COP12018D
)
CUP12018Z PCB , MAIN C715(291X216, FR-4, 2 ARRAY)
REF NO. PART NO. REMARKS
CUP12018Z MAIN BOARD
C101 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C103 CCUS1H222KC CAP , CHIP 2200PF 50V K
C104 CCUS1H222KC CAP , CHIP 2200PF 50V K
C108 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C110 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C111 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C113 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C114 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C115 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C116 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C117 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C120 CCUS1H101JA CAP , CHIP 100PF 50V J
C121 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C122 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C126 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C127 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C128 CCUS1H471JA CAP , CHIP 470PF 50V J
C129 CCUS1H471JA CAP , CHIP 470PF 50V J
C130 CCUS1H333KC CAP , CHIP 0.033UF 50V K
C131 CCUS1H333KC CAP , CHIP 0.033UF 50V K
C132 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C133 CCUS1H150JA CAP , CHIP 15PF 50V J
C134 CCUS1H150JA CAP , CHIP 15PF 50V J
C135 CCUS1H102KC CAP , CHIP 1000PF 50V K
C136 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C137 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C138 CCUS1H222KC CAP , CHIP 2200PF 50V K
C140 CCUS1H153KC CAP , CHIP 0.015UF 50V K
C141 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C142 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C143 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C144 CCUS1H470JA CAP , CHIP 47PF 50V J
C145 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C146 CCUS1H472KC CAP , CHIP 4700PF 50V K
C147 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C149 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C150 CCUS1H681JA CAP , CHIP 680PF 50V J
C151 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C152 CCUS1H153KC CAP , CHIP 0.015UF 50V K
C153 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C154 CCUS1H680JA CAP , CHIP 68PF 50V J
C155 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C156 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C157 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C401 CCUS1H101JA CAP , CHIP 100PF 50V J
C403 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C405 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C408 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C409 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C411 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C412 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C413 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C414 CCUS1H561JA CAP , CHIP 560PF 50V J
C415 CCUS1H561JA CAP , CHIP 560PF 50V J
C416 CCUS1H220JA CAP , CHIP 22PF 50V J
C417 CCUS1H220JA CAP , CHIP 22PF 50V J
C418 CCUS1H220JA CAP , CHIP 22PF 50V J
C422 CCUS1H221JA CAP , CHIP 220PF 50V J
C423 CCUS1H221JA CAP , CHIP 220PF 50V J
C424 CCUS1H221JA CAP , CHIP 220PF 50V J
C425 CCUS1H221JA CAP , CHIP 220PF 50V J
C426 CCUS1H221JA CAP , CHIP 220PF 50V J
C429 CCUS1H150JA CAP , CHIP 15PF 50V J
C430 CCUS1H150JA CAP , CHIP 15PF 50V J
C431 CCUS1H101JA CAP , CHIP 100PF 50V J C715DABC ONLY
C432 CCUS1H101JA CAP , CHIP 100PF 50V J C715DABC ONLY
C433 CCUS1H103KC CAP , CHIP 0.01UF 50V K
C434 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C435 CCUS1H104KC CAP , CHIP 0.1UF 50V K
C436 CCUS1H104KC CAP , CHIP 0.1UF 50V K
DESCRIPTION
SECTION 3
ELECTRICAL PARTS LIST
3-1
