NAD C715 - Page 42

Signal Name Shared Signal Pin # Type Description – TCC760
VDD_USB - 64 PWR Power for USB I/O (3.3V)
VDD_OSC - 71 PWR Digital Power for Oscillators (1.8V)
VDDI - 119
109
41
24
7
PWR Digital Power for Internal Core (1.8V)
VDDI_ADC - 87 PWR Digital Power for ADC (1.8V)
VDDA_ADC - 81 PWR Analog Power for ADC (3.3V)
VDDA_PLL - 77 PWR Analog & Digital Power for PLL (1.8V)
VSSIO - 97
65
45
32
1
GND Digital Ground for I/O
VSSI - 120
110
55
25
8
GND Digital Ground for Internal
VSSI_ADC - 88 GND Digital Ground for ADC
VBBA_ADC - 86 GND Analog Ground for ADC
VSSA_ADC - 85 GND Analog Ground for ADC
VBBA_PLL - 80 GND Analog Ground for PLL
VSSA_PLL - 79 GND Analog Ground for PLL
2-31
