31
COMPONENT VID (VIDEO SELECTION)
There are two YUV component outputs. The MONITOR OUT YUV includes the OSD. The
DIRECT MONITOR OUT has no OSD. NAD recommends that one connects the DIRECT
MONITOR OUT YUV to your monitor for NTSC (North American) video formats
480p/720p/1080i, and PAL (European) video formats 576p/720p/1080i.
Note: MONITOR OUT YUV which includes OSD, displays OSD when the input signal is
NTSC video format 480i and PAL video format 576i.
Component video may be assigned to any of your sources. Options are NONE, CV-1, CV-2,
and CV-3. These video inputs override VIDEO TYPE inputs. Thus select this input only if CVBS
or S-Video are not to be used.
HDMI INPUT (DIGITAL VIDEO SELECTION)
HDMI video may be assigned to any of your sources. Options are NONE, HDMI-1, and HDMI-
2. HDMI video may be assigned to any of your sources. These video inputs are available in
parallel of VIDEO TYPE and COMPONENT VIDEO inputs. Thus select this input only if HDMI
is to be used. as both source and monitor.
Note: HDMI OUT does not include the M15’s OSD. HDMI OUT is always active when a
source has assigned HDMI-1 or HDMI-2. See Quick Start figure 3 for monitor
connection.
SOURCE ENABLED
One can enable/disable an unused input via this option. This is particularly useful if only a few
inputs are used and one selects the inputs from the front panel controls, bypassing unused
inputs.
Note: The HTRM will always give you direct access to any input even though it may have
been disabled in the SETUP OSD.
USING THE M15
Setup
ENGLISH
FRANÇAISDEUTSCHNEDERLANDSESPAÑOL
ITALIANO
PORTUGUÊS
SVENSKA
