NAiS FP Series Technical Manual

FP0 RTD Unit
Unit Outline
1 Unit Outline
1.1 Functions
RTD input unit for the FP0/FPΣ control unit.
The temperature data obtained using the RTD (Resistance Temperature Detector) is
converted to the digital value to be read into the FP0/ FPΣ control unit.
Available RTD types
Pt100 (to IEC751), Pt1000 (to IEC751), Ni1000 (to DIN43760), and Resistor.
Temperature measurement ranges available
°C °F
RTD
Type
Resolution 0.1K Resolution 0.01K Resolution 0.1°F Resolution 0.01°F
Pt100 -200.0 … +500.0 -80.00 … +80.00 -328.0 … +800.0 -80.00 … +80.00
Pt1000 -200.0 … +300.0 -80.00 … +80.00 -328.0 … +572.0 -80.00 … +80.00
Ni1000 -30.0 … +150.0 -30.00 … +80.00 -22.0 … +302.0 -22.00 … +80.00
Resistor measurement ranges available
Ω
RTD
Type
Resolution 1 Ω Resolution 0.1 Ω
Resistor 20 … +2200 20.0 … 1630.0
Conversion to degrees Celsius or degrees Fahrenheit possible
The temperature data measured using the sensor is converted to degrees Celsius or degrees
Fahrenheit inside the FP0 RTD unit.
Broken-RTD detector attached
A broken RTD can be detected.
1.2 Product Number
Product name RTD input points Product number Part number
FP0 RTD unit 6 points FP0RTD6 AFP0430
1.3 Expansion Limit
Number
Up to 3 expansion units can be connected to the control unit.
Position
Always install the FP0 RTD unit the farthest to the right of the control unit.
1
