NAiS FP Series Technical Manual

FP0 RTD Unit
Specifications
7 Specifications
General specifications
Parameter Specifications
Increase of current
consumption in
control unit
25mA or less (24V DC)
Operating
temperature
0°C to +55°C
Storage
temperature
-20°C to +70°C
Operating humidity
30%RH to 85%RH (no condensing)
Storage humidity
30%RH to 85%RH (no condensing)
Vibration
resistance
10Hz to 55Hz, 1 cycle/min: double amplitude of 75mm for 10 min. on 3 axes (toward
X, Y and Z directions)
Shock resistance
98m/s
2
for 4 times on 3 axes (toward X, Y and Z directions)
Noise immunity
1000V [P-P] with pulse widths 50ns and 1µs (using noise simulator)
Operating
conditions
Free from corrosive gases and excessive dust.
Weight
Approx. 75g
Input specifications
Parameter Specification
Input channels
Up to 6 channels per unit
Resolution 0.1
-200.0°C to 500.0°C
-328.0°F to 800.0°F (see note 1)
Pt100
Resolution 0.01
-80.00°C to 80.00°C
-80.00°F to 80.00°F (see note 1)
Resolution 0.1
-200.0°C to 300.0°C
-328.0°F to 572.0°F (see note 1)
Pt1000
Resolution 0.01
-80.00°C to 80.00°C
-80.00°F to 80.00°F (see note 1)
Resolution 0.1
-30.0°C to 150.0°C
-22.0°F to 302.0°F (see note 1)
Ni1000
Resolution 0.01
-30.00°C to 80.00°C
-22.00°F to 80.00°F (see note 1)
Resolution 1
20Ω to 2200Ω
Input range
Resistor
Resolution 0.1
20.0Ω to 1630.0Ω
21
