Specifications
FP0 RTD Unit
Parameter Specification
Resolution 0.1
-200.0 to 500.0°C:
-328.0 to 800.0°F:
-2000 to 5000
-3280 to 8000
Pt100
Resolution 0.01
-80.00 to 80.00°C:
-80.00 to 80.00°F:
-8000 to 8000
-8000 to 8000
Resolution 0.1
-200.0 to 300.0°C:
-328.0 to 572.0°F:
-2000 to 3000
-3280 to 5720
Pt1000
Resolution 0.01
-80.00 to 80.00°C:
-80.00 to 80.00°F:
-8000 to 8000
-8000 to 8000
Resolution 0.1
-30.0 to 150.0°C:
-22.0 to 302.0°F:
-300 to 1500
-220 to 3020
Ni1000
Resolution 0.01
-30.00 to 80.00°C:
-22.00 to 80.00°F:
-3000 to 8000
-2200 to 8000
Resolution 1
20 to 2200Ω:
20 to 2200
Resistor
Resolution 0.1
20.0Ω to 1630.0Ω:
200 to 16300
Digital output
When out of range or RTD is broken: 8191 or 16383 (see note 2)
Until temperature can be measured at initial startup: see note 3
Resolution
0.1K/°F, 0.01K/°F
Sampling cycle
0.1 or 1s for all channels (see note 4)
Ambient temp.: 25°C 0.3K (-10°C to +30°C)
0.2%/1.4K (-200°C to +500°C)
Cycle 1s
Whole temp. range 0.35%/2.5K
Pt100
Cycle 0.1s Whole temp. range 0.5%/3.5K
Ambient temp.: 25°C 0.3K (-10°C to +30°C)
0.2%/1.0K (-200°C to +300°C)
Cycle 1s
Whole temp. range 0.35%/1.7K
Pt1000
Cycle 0.1s Whole temp. range 0.5%/2.5K
Cycle 1s Whole temp. range 1K
Ni1000
Cycle 0.1s Whole temp. range 2K
Cycle 1s Whole temp. range
1Ω (20 to 2200Ω)
Accuracy
Resistor
Cycle 0.1s Whole temp. range
2Ω (20 to 2200Ω)
Insulation
method
none
16 points for WX2, 4, 6 Analog input CH0, 2, 4 (WX2)
(see notes 5 and 6)
Input 32 points:
16 points for WX3, 5, 7 Analog input CH1, 3, 5 (WX3)
(see notes 5 and 6)
Input/output
points
Output 8 + 24 points (reserved)
NOTES
1. The measurement range available for degrees Celsius is larger than
for degrees Fahrenheit as the digital value (temperature value
displayed) for °F is higher than the one for °C.
2. When the RTD is broken, the digital value will change to 8191 or
16383. Use a program to avoid risks resulting from a broken RTD. A
broken RTD needs to be replaced.
