NANO D3 - Technical Specifications; Flow Rates

6
heatless desiccant air dryer
D3
2. technical specication
specications standard options
maximum water content (ISO class) class 2 -40°C (-40°F) pdp class 1: -70°C (-94°F) pdp
minimum operating pressure 4 barg (58 psig) -
maximum operating pressure 10 barg (145 232psig) 16 barg (232 psig)
recommended operating temp range 10 to 30°C (35 to 95°F) -
design operating temperature range 1.5 to 50°C (35 to 122°F) -
power supply requirements 100-240V AC @ 50-60 Hz 24V /DC
consult rating label, options and operating parameters may differ
ISO Class 2 at recommended max rated flow at 7 barg and 25°C inlet; see correction factors
2.1 ow rates
model
inlet ow rate connection
Nm
3
/hr scfm inlet outlet
NDL - 2110 360 212
2”
BSPP or NPT
2”
BSPP or NPT
NDL - 2120 469 276
NDL - 2130 680 400
NDL - 3130 951 560
NDL - 4130 1274 750
2 1/2”
BSPP or NPT
2 1/2”
BSPP or NPT
NDL - 6120 1407 828
NDL - 6130 1886 1110
