NANO D3 - Product Overview

8
heatless desiccant air dryer
D3
number description
1 compressed air inlet
2 compressed air outlet
3 standard controller display
4 premium controller display
5 column A pressure gauge
6 column B pressure gauge
7 control module access positions
8 enclosure access door
3. product overview
13
15
14
12
2 2
11 11
10
7
3
8
4
9*
5
6
1
1
number description
9 enclosure handle / lock
10 pressure vessel
11 exhaust silencer
12 inlet valve B
13 inlet valve A
14 exhaust valve B
15 exhaust valve A
