Name Part number Descriptions
Cable –Trillium Compact
Posthole to Nanometrics
Digitizer, Molded
17768-10M
17768-30M
A cable with a molded neoprene connector on
one end that connects to the Trillium Compact
Posthole connector and a connector on the
other end for connecting to a Nanometrics
digitizer. The cable features a robust neoprene
cable jacket that is suitable for buried
deployments.
In addition to connecting the analog inputs,
power, and control line signals to the digitizing
and data logging features of the digitizer, this
cable also provides access to the Web interface
of the seismometer through the Web interface
of the digitizer.
Cable – Trillium Compact
Posthole to Open End,
Molded
18005-5M
18005-10M
18005-30M
18005-70M
A cable with a molded neoprene connector on
one end that connects to the Trillium Compact
Posthole connector and is open-ended on the
other end.
In addition to connecting the analog inputs,
power, and control line signals to the digitizing
and data logging features of the digitizer, this
cable also provides access to the Web interface
of the seismometer through the Web interface
of the digitizer.
Adjustable Feet Kit 17245 A kit including three adjustable locking feet that
should be used on model numbers TC120-PH2,
TC20-PH2, TC120-PH2-XC and TC20-PH2-XC
instead of the default fixed studs in a surface
vault installation.
Lifting Cable Kit,
Compact/Titan Posthole
and Borehole, 1/8" 316SS,
Harsh Env
19251-xxM
where xx refers
to the cable
length in meters.
Compact/Titan Posthole and Borehole, 1/8"
316SS, Harsh Env.
For use when installing the Trillium Compact
Posthole in a deep cased hole. This kit includes a
lifting cable, cable clamps, cable ties. See Table
1-2 for a detailed component list.
Compact Holelock Kit (T-
CHL1)
18884 To adapt the Trillium Compact Posthole for
installation in a 107 mm to 129 mm borehole. Kit
includes holelock assembly for 107 mm to 129
mm borehole, adapter plate and mounting
screws. See instruction sheet Installing a
Nanometrics Sensor with a Cam Holelock (19026).
Table 1-1 - List of cables and accessories (Continued)
Chapter 1 - Getting Started
16889R10 • 2020-11-12 Page 14
