Napoleon BHD4N - Dimensions

W415-1285 / A / 11.03.14
5
EN
BHD4ST ILLUSTRATED
BHD4P ILLUSTRATED
38 1/4"
841mm
34 3/16"
868mm
43 1/4"
1099mm
8"
203mm
5"
127mm
12 13/16"
325mm
25 1/8"
638mm
RIGHT
SIDE
LEFT
SIDE
RIGHT
SIDE
LEFT
SIDE
7 9/16"
192mm
ELECTRICAL
INLET
7 9/16"
192mm
GAS
INLET
2 1/16"
53mm
34 3/16"
868mm
45"
1143mm
38 1/4"
841mm
7 9/16"
192mm
ELECTRICAL
INLET
7 9/16"
192mm
GAS
INLET
2 1/16"
53mm
8"
203mm
5"
127mm
25 1/8"
638mm
12 13/16"
325mm
SAFETY BARRIER
SAFETY BARRIER
2.1 DIMENSIONS
