Napoleon BL36NTE - MINIMUM COMBUSTIBLE MANTEL CLEARANCES

36
W415-1442 / C / 06.06.16
EN
Combustible Mantel clearance can vary according to the Mantel depth. Use the graph
to help evaluate the clearance needed. These same requirements apply to any
combustibles protruding on either side of the appliance.
!
WARNING
RISK OF FIRE, MAINTAIN ALL SPECIFIED AIR SPACE CLEARANCES TO COMBUSTIBLES. FAILURE
TO COMPLY WITH THESE INSTRUCTIONS MAY CAUSE A FIRE OR CAUSE THE APPLIANCE TO
OVERHEAT. ENSURE ALL CLEARANCES (I.E. BACK, SIDE, TOP, VENT, MANTEL, FRONT, ETC.) ARE
CLEARLY MAINTAINED.
WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE
HEAT RESISTANT TO PREVENT DISCOLOURATION.
73.1
5.6 MINIMUM COMBUSTIBLE MANTEL CLEARANCES
TOP OF APPLIANCE
OPENING
6"
152mm
8"8"
203mm
MANTEL
2"
51mm
4"
102mm
6"
152mm
8"
203mm
4"
102mm
2"
51mm
0
$
1
7
(
/
+
(
,
*
+
7

2" (51mm)
2 4 6 8 10 12
MANTEL DEPTH (INCHES)
4" (102mm)
6" (152mm)
10" (254mm)
12" (305mm)
8" (203mm)
