Napoleon Condo Pack - Page 12

12
IOM
IOM
W415-2288 / 08.29.2019
Flashing
Flashing
12 9/16"
16 "
Seal around Sleeve and OUTSIDE wall
Seal around
Sleeve and
INSIDE wall
PROTRUDE 1/2 ” MIN.-1” MAX.
Brick Wall
PROTRUDE 1/2 ” MIN.-1” MAX.
Brick Wall
82 "
REF.
A A
A-A
DRAIN
39 5/16 "
REF. *
ROUGH OPENING
TO SUIT
28 7/8 " X 44 7/8 "
WALL SLEEVE
VIEW OF
OUTSIDE WALL
8 " MIN.
2 " MIN. CLEARANCE TO
COMBUSTIBLE
***
SECURE
TO WALL
44 7/8 "
REF.
44 7/8 "
REF.
28 7/8 "
FLOOR
43 1/8 "
**B
***
**
*
NOTE
FABRICATED WOOD OR STEEL SUPPORT
(Refer to the manual for design options).
REFER TO FIGURE 4.2.1.A, PAGE 11.
FIG. 4.2.1.B
