9-6 Accessories
9.5
8053B Display Unit for EHP-50G
Fig. 9-4 8053B
EHP-50G can be easily operated using the Portable Field Meter 8053B as
a controller and display unit. In order not to influence the field to be
measured, communication between the EHP-50G Analyzer and the 8053
Unit is through a rugged optical fiber cable. The 8053B supports the
following settings and measurement modes:
• Electric or magnetic field selection (1 kV/m; 100 kV/m; 100 µT; 10 mT)
• Span selection (100 Hz … 400 kHz)
• Wideband or highest peak modes
• Spectrum Mode
• Monitor Mode (Actual; Max; Avg; Min)
• XYZ Mode (wideband or highest peak)
Additional features include:
• Alarm with adjustable thresholds for electric and magnetic field
• Averaging (4-32 samples) and Maximum Hold
• Full resolution spectrum marker
• Timer Logging
• Post-averaging for logged data on PC (RMS, Mean, Median)
For more information please refer to the 8053B product information on the
Narda website.
Fig. 9-5 8053 Logger Interface software supports evaluation and
documentation of results that have been saved on 8053B
