National Instruments 8353 User Manual

Chapter 2 Installation and BIOS Setup
© National Instruments Corporation 2-23 NI 8352/8353 User Manual
Installing Inner Slides
Follow these steps to install the inner slides:
1. Locate the right inner slide (the slide used on the right side of the
chassis when facing the chassis front panel).
2. Align the four square holes on the right inner slide against the hooks
on the right side of the chassis, as shown in Figure 2-1.
3. Securely attach the slide to the chassis with two M4 flathead screws.
Repeat steps 1–3 to install the left inner slide to the left side of the
chassis.
Figure 2-1. Installing Inner Slides
1 Hooks on Chassis 2 Square Holes on Right Inner Slide 3 Holes for M4 Screws
1
3
2
