Chapter 3 I/O Information
© National Instruments Corporation 3-5 NI 8352/8353 User Manual
VGA
Figure 3-5 shows the location and pinouts for the VGA connector on the
NI 8352/8353. Table 3-5 lists and describes the VGA connector signals.
AMP manufactures a mating connector with part numbers 748364-1
(housing) and 748333-2 (pin contact).
Figure 3-5. VGA Connector Location and Pinout
VGA
15
10
5
11
6
1
