© National Instruments Corporation 3-1 NI 8352/8353 User Manual
3
I/O Information
This chapter describes the NI 8352/8353 I/O connectors.
Rear Panel Connectors
Table 3-1 lists various peripherals and their corresponding NI 8352/8353
external connectors, bus interfaces, and functions.
Table 3-1. NI 8352/8353 Peripherals Overview
Peripheral External Connector Description
Keyboard PS/2 (5-pin Din) PS/2-style keyboard
Mouse PS/2 (5-pin Din) PS/2-style mouse
USB USB 4-pin Series A stacked
receptacle
USB 2.0 capable
USB USB 4-pin Series A stacked
receptacle
USB 2.0 capable
Serial COM1 (9-pin DSUB) 16550 RS-232 serial port
Video VGA (15-pin DSUB) Intel Extreme Graphics controller
Ethernet LAN (RJ45) 10/100/1000 Ethernet connection
Ethernet LAN (RJ45) 10/100/1000 Ethernet connection
