Chapter 7 Counters
X Series User Manual 7-42 ni.com
Routing a Signal to Counter n Source
Each counter has independent input selectors for the Counter n Source
signal. Any of the following signals can be routed to the Counter n Source
input:
• 100 MHz Timebase
•20MHz Timebase
• 100 kHz Timebase
•RTSI<0..7>
• PFI <0..15>
•PXI_CLK10
•PXI_STAR
• PXIe-DSTAR<A,B>
• Analog Comparison Event
• Change Detection Event
In addition, TC or Gate from a counter can be routed to a different counter
source.
Some of these options may not be available in some driver software.
Routing Counter n Source to an Output Terminal
You can route Counter n Source out to any PFI <0..15>, RTSI <0..7>, or
PXIe-DSTARC terminal. All PFIs are set to high-impedance at startup.
Table 7-8. Counter Applications and Counter n Source
Application Purpose of Source Terminal
Pulse Generation Counter Timebase
One Counter Time Measurements Counter Timebase
Two Counter Time Measurements Input Terminal
Non-Buffered Edge Counting Input Terminal
Buffered Edge Counting Input Terminal
Two-Edge Separation Counter Timebase
