Chapter 9 Digital Routing and Clock Generation
X Series User Manual 9-6 ni.com
Using RTSI as Outputs
RTSI <0..7> are bidirectional terminals. As an output, you can drive any of
the following signals to any RTSI terminal:
• AI Start Trigger (ai/StartTrigger)
• AI Reference Trigger (ai/ReferenceTrigger)
• AI Convert Clock
*
(ai/ConvertClock)
• AI Sample Clock (ai/SampleClock)
•AI Pause Trigger (ai/PauseTrigger)
• AO Sample Clock
*
(ao/SampleClock)
• AO Start Trigger (ao/StartTrigger)
•AO Pause Trigger (ao/PauseTrigger)
• DI Start Trigger (di/StartTrigger)
• DI Sample Clock (di/SampleClock)
•DI Pause Trigger (di/PauseTrigger)
• DI Reference Trigger (di/ReferenceTrigger)
• DO Start Trigger (do/StartTrigger)
• DO Sample Clock
*
(do/SampleClock)
• DO Pause Trigger (do/PauseTrigger)
• 10 MHz Reference Clock
•Counter n Source, Gate, Z, Internal Output
• Change Detection Event
• Analog Comparison Event
RTSI 2 24
RTSI 1 22
RTSI 0 20
Not Connected. Do not connect
signals to these terminals.
1–18
DGND 19, 21, 23, 25, 27, 29, 31, 33
Table 9-1. RTSI Signals (Continued)
RTSI Bus Signal Terminal
