Chapter 9 Digital Routing and Clock Generation
X Series User Manual 9-10 ni.com
Table 9-2 describes the three differential star (DSTAR) lines and how they
are used.
The DSTAR lines are only available for PXI Express devices when used
with a PXI Express system timing module. For more information, refer to
the PXI Express Specification at
www.pxisa.org.
Table 9-2. PXIe-DSTAR Line Descriptions
Trigger Line Purpose
PXIe_DSTARA Distributes high-speed, high-quality clock signals
from the system timing slot to the peripherals
(input).
PXIe_DSTARB Distributes high-speed, high-quality trigger
signals from the system timing slot to the
peripherals (input).
PXIe_DSTARC Sends high-speed, high-quality trigger or clock
signals from the peripherals to the system timing
slot (output).
