Appendix A Device-Specific Information

NI PCI-6071E Pinout

Figure A-87 shows the NI 6071E device pinout.

Note Some hardware accessories may not yet reflect the NI-DAQmx terminal names. If

you are using an E Series device in Traditional NI-DAQ (Legacy), refer to Table 1-5,

Terminal Name Equivalents, for the Traditional NI-DAQ (Legacy) signal names.
