Chapter 5 Calibration
PCI E Series RLPM 5-8
© National Instruments Corporation
420 CALDAC factory constant Unipolar AI 8800
(8-bit)
3 0
419 CALDAC factory constant Unipolar AI 8800
(8-bit)
0 0
418 CALDAC factory constant Unipolar AI 8800
(8-bit)
1 0
417 CALDAC factory constant Bipolar AO 8800
(8-bit)
6 0
416 CALDAC factory constant Bipolar AO 8800
(8-bit)
4 0
415 CALDAC factory constant Bipolar AO 8800
(8-bit)
7 0
414 CALDAC factory constant Bipolar AO 8800
(8-bit)
5 0
413 CALDAC factory constant Unipolar
AO
8800
(8-bit)
6 0
412 CALDAC factory constant Unipolar
AO
8800
(8-bit)
4 0
411 CALDAC factory constant Unipolar
AO
8800
(8-bit)
7 0
410 CALDAC factory constant Unipolar
AO
8800
(8-bit)
5 0
409 Factory calibration
temperature
— — — —
371 Start of the five user
calibration sections
— — — —
1
Board Codes:
204—PCI-MIO-16XE-10
220—PCI-6031E
221—PCI-6032E
222—PCI-6033E
Table 5-3. PCI-MIO-16XE-10, PCI-6031E, PCI-6032E, and PCI-6033E EEPROM Map (Continued)
EEPROM
Address
Data Stored at EEPROM
Address
Data Type
CALDAC
Type
CALDAC
Address
Ser
DacLd
Line
