National Instruments PCI E Series Programmer's Manual

Chapter 5 Calibration
PCI E Series RLPM 5-12
© National Instruments Corporation
Table 5-6. PCI-6052E EEPROM Map
EEPROM
Address
Data Stored at EEPROM
Address
Data Type
CALDAC
Type
CALDAC
Address
Ser
DacLd
Line
511 NI-DAQ Board Code
LSB:17
1
— — — —
474 NI-DAQ Board Code
MSB:1
1
— — — —
510 Revision — — — —
509 Sub-revision — — — —
508 Year of last factory
calibration
— — — —
507 Month of last factory
calibration
— — — —
506 Day of last factory
calibration
— — — —
416 Factory reference MSB — — — —
415 Factory reference LSB — — — —
414 CALDAC factory constant AI pregain
offset coarse
MB88341 0 0
413 CALDAC factory constant AI pregain
offset fine
MB88341 8 0
412 CALDAC factory constant AI postgain
offset coarse
MB88341 4 0
411 CALDAC factory constant AI postgain
offset fine
MB88341 12 0
410 CALDAC factory constant AI gain
coarse
MB88341 2 0
409 CALDAC factory constant AI gain fine MB88341 10 0
408 CALDAC factory constant AI unipolar
offset coarse
MB88341 14 0
407 CALDAC factory constant AI unipolar
offset fine
MB88341 7 0
