National Instruments PCI E Series Programmer's Manual

Chapter 3 Register Map and Descriptions
PCI E Series RLPM 3-6
© National Instruments Corporation
Status Register
The Status Register is used to indicate the status of the calibration EEPROM output.
Address: Base address + 01 (hex)
Type: Read-only
Word Size: 8-bit
Bit Map:
Bit Name Description
7–1 Reserved Reserved—Ignore returned bits.
0 PROMOUT EEPROM Output Data—This bit reflects the serial output
data of the serial EEPROM.
7 6 5 4 3 2 1 0
Reserved Reserved Reserved Reserved Reserved Reserved Reserved PROMOUT
