Chapter 3 I/O Information
NI PXI-8109 User Manual 3-8 ni.com
Table 3-6. Parallel Port Connector Signals
Pin
Default Configuration (LPT)
Signal Name Signal Description
1 BUSY Device Busy
2 SLCT Select
3 ACK# Acknowledge
4 FAULT#(ERROR#) Fault
5 PAPE REND Paper End
6 PD0 Data Bit 0
7 PD1 Data Bit 1
8 PD 2 Data Bit 2
9 PD3 Data Bit 3
10 PD4 Data Bit 4
11 PD5 Data Bit 5
12 PD6 Data Bit 6
13 PD7 Data Bit 7
14 INIT# Initialize Printer
15 STROBE# Strobe
16 SLCTIN# Select Input
17 AUTOFD# Auto Line Feed
18 +5V +5 V
19–35 GND Ground
36 NC Not Connected
