PXIe-4466/4467 Calibration Procedure
© National Instruments Corporation 33
Function DC Volts (DCV)
Range Fixed - 10 V
Number of Power Line Cycles (NPLC) 100
MATH NULL Enabled
3. Configure an AO Voltage channel task using the values in Table 25.
Table 25: AO Setup
Configuration Value
Physical Channels Dev_name/aox
Output Terminal Configuration Differential
Rate 250000 S/s
Sample Mode Continuous Sample
Samples Per Channel 25000
Common-mode voltage Test Value from Table 23
4. Create an array of 25000 points and fill every element with value 0.
5. Write the array to AO.
6. Start the task.
7. Measure the output voltage on the DMM.
8. Stop and clear the task.
9. Compare this value to the limits in Table 23.
