Appendix A Device-Specific Information

NI USB-621x User Manual A-22 ni.com

Figure A-14. USB-6218 BNC Top Panel and Pinout

NI USB-6218

AI x +

AI x –

0.1 µF

5 kΩ

AI GND

–

USB-621x Device

Floating

Source

AI x +

AI x –

0.1 µF

5 kΩ

AI GND

–

USB-621x Device

Ground-

Referenced

Source
