Traces Display Mode
Waveforms are displayed sequentially in time according to the display mode of the group. A maximum of
50 traces are displayed consecutively. –See below examples of traces Stack. Note that traces can also
be displayed as Sets Stack.
Display Mode Illustration Description
Vertical Curve Stack
Single traces
Overlay
Sets of superimposed traces.
Replace
Each new acquired waveform
replaces the previous one.
