NV10LT/NV7.5LT INSTALLATION MANUAL PREPARING FOR INSTALLATION
PAGE 2.1.2 VERSION 5.0 2021-03-01
7. Review any assembly notes or instructions contained inside the transmitter crates. (For sites
requiring custom configurations, the instructions provided with the transmitter replace the
instructions provided here.)
8. Assemble your parts and tools. For a list of required tools, see “Parts and Tools” on page 2.10.1.
9. When you are ready to install the NV10LT/NV7.5LT transmitter, follow the steps shown in
Figure 2.1.2.
Figure 2.1.2: Flowchart - Installing the transmitter
TIP When you have completed a task or step, put a check mark beside the step number.
CAUTION! FAILURE TO COMPLY WITH RECOMMENDATIONS MAY VOID YOUR
MANUFACTURER’S WARRANTY. FOR MORE INFORMATION, REVIEW YOUR
WARRANTY DOCUMENT
.
Connecting to Station Reference Ground - see page 2.4.1
Connecting Ac Power - see page 2.5.1
Installing the RF Feed Cable - see page 2.6.1
Unpacking and Positioning - see page 2.2.1
Installing Options - see page 2.3.1
Installing Program Inputs - see page 2.7.1
Installing Control/Monitor Wiring - see page 2.8.1
Commissioning - see page 2.9.1
