NV10LT/NV7.5LT INSTALLATION MANUAL UNPACKING AND POSITIONING
VERSION 5.0 2021-03-01 PAGE 2.2.3
Figure 2.2.1: Front and Rear Access Panels
1/4-TURN LATCHES
8 in front panel
12 in rear panel
LOWER, REAR PANEL
10 M5 screws
LOCK OUT AC POWER
BEFORE REMOVING!
