VX3 TO VX6 INSTALLATION MANUAL PHYSICAL REQUIREMENTS
VERSION 1.0 2023-08-16 PAGE 1.3.1
SECTION 1.3: PHYSICAL REQUIREMENTS
This section provides physical specifications for the VX3 to VX6 transmitter and its components, and
lists physical site requirements.
Dimensions and Weights
Dimensions and weights for the VX3 to VX6 transmitter are shown in Table 1.3.1. Use additional
assistance to lift the transmitter for installation and maintenance.
Table 1.3.1: VX3 to VX6 Dimensions and Weights
Clearances
There are no clearance restrictions for the top and bottom of the transmitter.
Check the clearance around the host cabinet to ensure that you will be able to open all doors and
access panels. Ensure adequate space is available at the front of the cabinet to allow pulling out the
transmitter for servicing fan filters and internal parts/assemblies. Also consider access to the rear of the
cabinet for making connections to the transmitter.
Internal fans pull cooling air through air filters in the front of the transmitter. Air exhausts through grills
at the rear of the transmitter.
ITEM
HEIGHT
WIDTH DEPTH
WEIGHT
(PACKED)
WEIGHT
(UNPACKED)
IN CM RU IN CM IN CM LBS KG LBS KG
Overall Transmitter 10.5 26.7 6 19* 48.3* 24.92 63.3 102 46.3 80 36.3
Overall Transmitter
(power supplies removed)
10.5 26.7 6 19* 48.3* 24.92 63.3 N/A N/A 50 22.6
Exciter/Controller Assembly 3.5 8.9 2 19* 48.3* 19.88 50.5 N/A N/A 15 6.8
Amplifier Assembly
(with 1 5/8 inch flange)
7 17.8 4 19* 48.3* 24.92 63.3 N/A N/A 65 29.5
Amplifier Assembly
(without 1 5/8 inch flange)
7 17.8 4 19* 48.3* 24.32 61.8 N/A N/A 65 29.5
NOTE: * - minimum rack opening of 17.5 in (44.cm) is required.
