Nautilus Bowflex VeloCore User Manual

Assembly / Owner’s Manual
12
NOTICE: Push the extra wire down into the Console Mast. Reinstall the console hardware (*). Install the Console Mast End Cap (13) and Console mast
cover (12a). Do not crimp the cables.
Make sure the Console and Console Mast are straight, then fully tighten the screws at the base of the Console Mast..
13
12a
13
*
*
*
*
12a
7. Install the Console to the Frame Assembly
NOTICE: Remove the Console mast cover (12a) and pre-installed hardware(*) from the back of the Console before you connect the cables.
Route the Console cable through the Console Mount up to the opening at the top. Connect the Console cable and Console Mast cable. Do not crimp the
cables.
12
12
12a
*
*
X4
12
#2
