37
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and the
machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a secure location.
Note: Your machine may not match the image. For reference only.
1. Using a 6mm hex key and a 13 mm wrench, remove the 2 indicated
bolts from the Lower Handlebar Arms and Pedals. Set the hardware safely
aside for reassembly.
Be aware that the Handlebar Arms will be loose and may pivot
when the hardware is removed. This step may require two people.
2. Using a small flathead screwdriver, pry the Caps from the Lower
Handlebar Arms.
3. Using a 13 mm wrench, remove the hardware from the Lower Handle-
bar Arms and the Arm Pivot Rod. Remove the hardware and Upper and
Lower Handlebar Arms. Set them safely aside for reassembly.
X2
13 mm
X2
6mm
X2
To Next Page
