Nautilus E614 User Manual

7
Condition/Problem Things to Check Solution
Check magnet position
(requires shroud removal)
Magnet should be in place on pulley.
Check Speed Sensor
(requires shroud removal)
Speed sensor should be aligned with magnet and connected to
data cable. Realign sensor if necessary. Replace if there is any
damage to the sensor or the connecting wire.
Fan will not turn on or will
not turn off
Check data cable integrity All wires in cable should be intact. If any are cut or crimped,
replace cable.
Check data cable
connections/orientation
Be sure cable is connected securely and oriented properly.
Small latch on connector should line up and snap into place.
Reset machine Unplug unit from electrical outlet for 3 minutes. Reconnect to
outlet.
Fan will not turn on, but
Console operates
Check for blockage of fan Unplug unit from electrical outlet for 5 minutes. Remove mate-
rial from fan. If necessary, detach the Console to help with
removal. Replace the Console if unable to remove blockage.
Unit rocks/does not sit
level
Check leveler adjustment Adjust levelers until machine is level.
Check surface under unit Adjustment may not be able to compensate for extremely
uneven surfaces. Move machine to level area.
Check for loose hardware Tightly secure all hardware on the Stabilizers and the base of
the Console Mast.
Foot pedals loose/unit
difculttooperate
Hardware Tightly secure all hardware on the Pedal Arms and Handlebar
Arms.
Drivetrainclick/tick
noise once per full crank
revolution
Check crank/pulley
assembly
Disconnectleftandrightfootassembliesandrotatecrank.If
sound persists, replace crank/pulley assembly. If sound does
not come from rotating crank, check foot assemblies and up-
per/lower handlebars.
Check foot assemblies,
leg assemblies, handlebar
assemblies
Manually move foot, leg, and handlebar assemblies to isolate
sound. Replace part making sound.
Check for loose hardware Tightly secure all hardware on the Stabilizers and the base of
the Console Mast.
Squeaking noise
that appears a few
minutes into a workout
and normally will get
progressively worse as
the workout continues
Bolt that connects the
swing arms to the axle
running through the
console mast
Loosen pivot rod bolt slightly until noise goes away. White
lithiumgreasecanalsobeappliedforatemporaryx.Contact
Customer Care for assistance.
Roller squeaking on rail Apply silicone lubricant to a dry cloth and wipe the rails to
eliminate roller noise.
Incline assembly sticks/
difculttoadjust
Check position of incline
assembly
Adjust levelers to raise the front of rail assembly until there
is 0.6cm - 1.25cm (1/4” - 1/2”) space between the top of the
incline assembly and the main unit shroud.

Nautilus E614 Specifications

General

Brand	Nautilus
Model	E614
Category	Elliptical Trainer
Language	English
