Nautilus E616 Service Manual

28
5. Using a 6 mm hex key, remove the remaining bolt (B, from Step 2)
again, and remove the Static Handlebar.
NOTICE:'RQRWFULPSWKHFDEOHVZKHQUHPRYLQJWKH6WDWLF+DQGOHEDU
'RQRWDOORZWKHFDEOHVWRIDOOGRZQLQWRWKH&RQVROH0DVW8VH
a rubber band or wire tie.
6. Installation is the reverse procedure.
NOTICE:'RQRWFULPSWKHFDEOHV
7.'LVSRVHRIWKHROGSDUWV
8. Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
MY14 static handlebar shown

Nautilus E616 Specifications

General

Type	Upright
Programs	29
Bluetooth Connectivity	Yes
User Profiles	4
Drive System	Belt
Display	LCD
Heart Rate Monitoring	Contact and Telemetry Enabled
Max User Weight	300 lbs
Warranty	10 years frame, 1 year labor
Flywheel	Perimeter Weighted
Product Weight	78.5 lbs (35.6 kg)
