Nautilus E616 Service Manual

31
X2
13 mm
X2
6mm
5. Using a small Flathead screwdriver, pry the Caps from the Lower
Handlebar Arms.
6. Using a 13 mm wrench, remove the hardware from
the Lower Handlebar Arms and the Arm Pivot. Remove
the Handlebar Arms and set them safely aside.
7. Installation is the reverse procedure.
Make sure the Upper Handlebar Arms are secure before you
exercise.
8.'LVFDUGWKHROGSDUWV
9. Inspect your machine to ensure that all hardware is tight and compo-
nents are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.

Nautilus E616 Specifications

General

Type	Upright
Programs	29
Bluetooth Connectivity	Yes
User Profiles	4
Drive System	Belt
Display	LCD
Heart Rate Monitoring	Contact and Telemetry Enabled
Max User Weight	300 lbs
Warranty	10 years frame, 1 year labor
Flywheel	Perimeter Weighted
Product Weight	78.5 lbs (35.6 kg)
