HARDWARE / TOOLS
Tools
Included Not Included
(recommended)
4 mm
6 mm
Item Qty Description Item Qty Description
A 8 ButtonHeadHexScrew,M8x16 F 2 PhillipsHeadScrew,M5x12
B 10 ButtonHeadHexScrew,M6x12 G 14 Lock Washer, M6
C 8 Flat Washer, M8 H 4 Curved Washer, M6
D 8 Lock Washer, M8 I 4 PhillipsHeadScrew,M6x25
E 10 Flat Washer, M6
A B C D E F
G H
I
